Product model:Fixed biomass environment-friendly boiler

Release time:2017-05-17 Browse number:200people information sources:

Automatic control of indoor temperature Automatic control of coal feeding quantity

Automatic control of hot water circulation Automatic fire prevention to maintain combustion

Automatic alarm of abnormality Colorless smoke discharge and environmental protection

Quick temperature rise and stable thermal power Convenient operation and beautiful appearance


tel:024-23712222

Product introduction

1. Full automatic, display of current operating state.

2. In the event of fault, or in case the boiler needs to be inspected, fault code, inspection items and alarm, etc. will be displayed on the LCD screen in red.

3. The upward boiler feeds materials from the center of stove, so the combustion and smoke discharge are stable.

4. The fire of feeding type boiler in the central stove generates thermal decomposition gas from the center, so the gas and dust are little.

5. Automatic electric firing.

6. Grate combustion rate: more than 98%.

7. The automatic ash removal device on the grate automatically discharges the coking generated during combustion to the boiler ash bucket.

8. Three-cycle access structure with the maximum boiler efficiency.

9. The observation window at the upper part of pipe facilitates the cleaning of pipe.

10. Safety devices of back-fire prevention, minimum water level prevention, overheating prevention and frost crack prevention, etc. are provided.


Application scope


Configuration and parameters

Boiler model Boiler power Heat supply area (m2) Operation pressure(Mpa)
Heat efficiency (%)
Fuel
Fuel consumption(kg/h)
Material feeding method
Rated water outlet/return (℃)
exhaust volume (M3/h)
Water capacity of boiler (kg)
Rated voltage(V/kw)
Kcal/h t/h
CZSA-0.12 10x104 0.16 800~1100 Atmospheric pressure 85% above Biomass 25~29 Automatic 85/60 880 1240 380/1.5
CZSA-0.24 20x104 0.35 1700~2100 Atmospheric pressure 85% above Biomass 50~58 Automatic 85/60 1100 1706 380/1.6
CZSA-0.35 30x104 0.5 2400~3000 Atmospheric pressure 85% above Biomass 75~88 Automatic 85/60 1300 2261 380/2.45
CZSA-0.49 40x104 0.67 5700~6000 Atmospheric pressure 85% above Biomass 150~176 Automatic 85/60 1500 3221 380/8


Use fuel


Product qualification

Case display

Learn more
